1. Suitable for transferring clean water or other liquids which are not chemically aggressive to the pump components.
2. Widely used in well water lifting, garden irrigation, vegetable greenhouse water supply, breeding industry water supply and drainage, pipeline boosting, etc.
1. Reliable, economical and simple to use.
2. 304 Stainless steel pump body & pump cover, meet drinking water standards
3. Hydraulic optimization design, excellent performance
The pump should be installed in a covered area, protected against the bad weather. It is always advisable to install a foot valve or a non return valve on the suction opening.
1. Maximum Liquid temperature:+40℃
2. Maximum Ambient temperature:+40℃
3. Maximum Suction: 9m
4. Protection class: Ip44
5. Insulation class: B
1. Copper winding motor
2. Single-phase: 220V-240V/50Hz
3. Three-phase: 380V-415V/50Hz
4. Single-phase with capacitor and thermal overload protection.
1. Special request for mechanical seal, bearing or shaft
2. Other voltages or frequency: 60HZ
